Home > DIP LEDs >

4.8mm straw hat Clear Leds|straw hat LEDs|straw hat Lamps| straw hat|Light Bulbs|4.8mm straw hat Clear Lens

Product Categories

Guangdong Queendom Group Technology Co., Ltd.

Contact Now

Name: 48mm straw hat Clear Ledsstraw hat LEDsstraw hat Lamps straw hatLight Bulbs48mm straw hat Clear Lens
Brand: Queendom
Price: 1 USD

Place of Origin : china

Brand Name : Queendom

MOQ : 1000

Delivery Time : 7-15

Payment Terms : T/T

Model Number : F4.8mm LEDs

Certification : SGS certificate in linewith EU ROHS, EN60425, REACH standards

Packaging Details : Tray: 1000PCS/bag anti-static bag

Contact Now

Model: 4.8mm straw hat Clear Leds Size: 4.8mm

Peak parameters:

Ø Absolute Maximum Rating(At TA=25°C)	Symbol	Ratings	Units
Parameter	PD	60	mW
Continuous Forward Current	I_F	20	mA
Peak Forward Current ＊1	I_FP	100	mA
Reverse Voltage	V_R	5	V
Thermal Resistance Junction To Board	RΘ_J-B	/	°C/W
Operating Temperature Range	T_OPR	Minus 30°C To plus 60°C
Storage Temperature Range	T_STG	Minus 40°C To plus 80°C
Manual Solding Temperature	T_SOL	260°C± 10°C For 3~5 Seconds
ESD Sensitivity	ESD	2000V HBM

Note:1. Derate linearly as shown in Figure 4 for temperature above 25°C.

Product number::Absolute Maximum Rating(At TA=25°C)

Notes:

Luminous intensity is measured with a light sensor and filtercombination that approximates the CIE eye-response curve.2θ_1/2

is the o-axis angle where the luminous intensity is 1⁄2the peak intensity.c. The dominant wavelength (λd) is derived from

the CIEchromaticity diagram and represents the single wavelength which defines thecolor of the device.

4.8mm straw hat Clear Leds|straw hat LEDs|straw hat Lamps| straw hat|Light Bulbs|4.8mm straw hat Clear Lens Images
